Intermediate flange flaps

Intermediate-
flanged flaps

Ring throttle valve GD-6

Ring Ouzel-
flap GD-6

> Diameter (DN) <

65 – 3000

> Installation type <

Intermediate flange flap

> Operating temperatures <

up to +1100°C

The ring butterfly valve GD-6 is clamped between flanges (PN-6 to PN-16) in pipelines. Depending on the application, we manufacture this flap from any material available on the market.

Special designs regarding dimension, actuation or medium are possible at any time.

GD6
GD-6
Diameter (DN)  65 – 3000
Installation type Intermediate flange
Connection dimensions All common flange standards and special dimensions
Operating temperatures up to +1100°C
Actuation types
  • With free shaft end
  • Manual adjustment via ratchet handle
  • Continuous fine adjustment
  • Manual gearbox
  • Mounting kit according to DIN ISO 5211 with corresponding shaft adaption
  • Attached drive (pneumatic, electric, hydraulic)
Closure types and tightnesses
Resounding 1% from Kv 90
with stop bar in housing 0.5% from Kv 90°.
with stop bar and sealing insert 0.05% of Kv 90°
Column 1 Value 10 Column 2 Value 10

Download GD-6 Catalog (PDF)
